Gayatri tubes is the renowned manufacturer that produces the wider ranges of Alloy Steel P5 Pipes. We as a client-focused industry is providing these pipes in different dimensions, standards, sizes, wall thickness, forms, outer diameter, ends, forms, lengths, ends, and schedules. Considering the special demands it is provided to them at cut-built specifications and standards. We catering to the needs of different applications are providing these Alloy Steel P5 Pipes in different types like alloy steel P5 seamless pipes, P5 alloy steel bush hex pipes, alloy steel chrome Moly P5 pipes, Alloy steel P5 round pipes, Alloy Steel P5 custom pipes.
Our product due to very good features in it is found effectively used in many industrial applications. Some of those are power generation, petrochemicals, gas processing, and condensers. Also it is used in pulp & paper industry, pharmaceuticals, specialty chemicals, sea-water equipment, etc. The control of nitrogen and carbon and proper selection of molybdenum, chromium, tungsten level, the corrosion resistance properties have been attained such as of alloy steel P5 seamless pipes. Operating conditions in Alloy Steel P5 Seamless Pipes of the flue gas desulfurization system for corrosion-resistant material is providing a demanding atmosphere.
However hot working temperature range for P5 EFW pipes are ranging 870 deg to 1230 deg C and after hot working, P5 ERW pipes must be water quenched where the heat treatment is suggested after the hot working for enhancing the ability of corrosion resistance. P5 Alloy steel round pipes work very well into the sea-water particularly into the crevice conditions wherein SS is the frequently used alloy. If the process of annealing in the oxidizing atmosphere is carried out, the scailing has to be removed in P5 electro polished pipes through pickling.
Alloy steel pipes are tubular with a greater percentage than the AS pipes of alloyants like nickel, chromium, molybdenum, etc. These pipes contain the total sum of alloyants below 5%. The addition of alloyants in a greater percentage transforms steel into high alloys. Alloy steel pipes for the very low temperature and high-temperature services are used in the energy industries. Also is used for the applications with the high pressure. Molybdenum addition enhances strength, harden-ability, softening resistance, etc. Chromium enhances yielding and tensile strength and hardness property.
| STANDARD | UNS | WERKSTOFF NR. | TRADE NAME |
| Alloy Steel P5 | K41545 | 1.7362 | 5Cr-1/2Mo |
| Specifications | ASTM A335 / ASME SA335 |
| Standard | ASTM, ASME and API |
| Dimension Standard | ANSI B36.19M, ANSI B36.10 |
| Size | 1/8"NB TO 30"NB IN |
| Length | Single Random, Double Random & Required Length, Cut Length |
| Type | Seamless |
| End | Plain End, Beveled End, Treaded |
| Grade | C | Mn | Si | S | P | Mo | Cr |
| Alloy Steel P5 | 0.05-0.15 | 0.30-0.60 | 0.50-1.00 | 0.025 max | 0.025 max | 0.44-0.65 | 1.00-1.50 |
| Element | Tensile Strength, MPa | Yield Strength, MPa | Elongation, % |
| Alloy Steel P5 | 415 min | 205 min | 30 % |
