Gayatri Tubes is introducing high-quality grade Hastelloy C22 Fasteners . We manufacture, supply and even export these fasteners to the industries of different sectors. Our manufactured fasteners are available in varied shapes and sizes. Hastelloy c22 is a versatile grade that is composed of elements such as nickel, chromium, tungsten, and molybdenum. The alloy increases the resistant properties of fasteners making them workable in crevice corrosion cracking, stress corrosion cracking and even pitting. The increased amount of chromium increases its resistant ability in oxidizing media. Molybdenum and tungsten elements give it good resistant ability in reducing media. The presence of nickel makes it useful in oxidizing aqueous media. The fasteners are useful for acetic acid, formic acid, and well-wet chlorine-containing environments.
In organic and inorganic containing conditions Hastelloy C22 Fasteners offer long-lasting service. Several types of fasteners are manufactured at Gayatri Tubes. These include stud bolts, socket hexagon screw, mushroom head square neck, U-bolts, screw, nuts, cap screw, machine screw, wing screw, structural bolts, eye, J bolts, hex coupling nut, Allen cap screw, and hex head bolts. More varieties of fasteners are available at us. Carriage bolts fasteners are also called as coach bolt. They have a countersunk head. They have a square section below the head that prevents the fastener from turning while tightening the nut. Hastelloy c22 Fasteners hex head bolt is driven using a wrench. They are known as bolt and screws as well.
The screw with a flat point is a machine screw that comes in a variety of heads and drives types. Washer and nut are used along with machine screws in a variety of applications. Stovers are another name of machine screws. Installing them is easy with a socket driver or directly using a hand. Application industries of 2.4602 Fasteners are chemical, condensers, seawater, pharmaceuticals, gas processing, petrochemicals, specialty chemical, power generation, heat exchangers, and pharmaceutical equipment. Hastelloy c22 Fasteners are tested and tests like hardness, tensile, PMI, IGC, mechanical, flaring, pitting resistance, chemical analysis, flattening, micro and macro, and more are done. We pack them in durable packaging materials for safe delivery. This ensures safety and long lasting performance of fasteners.
| STANDARD | UNS | WERKSTOFF NR. | AFNOR | EN | JIS | BS | GOST |
| Hastelloy C22 | N06022 | 2.4602 | - | NiCr21Mo14W | NW 6022 | - | - |
| Specifications | ASTM B574 / ASME SB574 |
| Standard | DIN, ASTM, BS and all International Standards |
| Nuts Size | M3 - M56 | 3/6" to 2" | Custom Sizes |
| Bolt / Screw Size | M3 - M56 | 3/6" to 2" | Custom Sizes |
| Washers Size | M3 - M56 | 3/6" to 2" | Custom Sizes |
| Machine Screws Size | M1.6 - M12 |
| Self Tapping Screw Size | No.2 - No. 14 |
| Length | 3 mm to 200 mm |
| Grade | C | Mn | Si | S | Co | Ni | Cr | Fe | Mo | P |
| Hastelloy C22 | 0.010 max | 0.50 max | 0.08 max | 0.02 max | 2.50 max | 50.015 min* | 20.00 – 22.50 | 2.00 – 6.00 | 12.50 – 14.50 | 0.02 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.69 g/cm3 | 1399 °C (2550 °F) | Psi – 1,00,000, MPa–690 | Psi – 45000, MPa–310 | 45 % |
