Gayatri Tubes is the renowned manufacturer and distributor of the very good quality of Inconel 601 Forged Fittings. Inconel Forged Fittings is having very good temperature strength and it retains the ductility after getting exposed to the long services. Also, it is having very good corrosion resistance ability under the oxidizing atmosphere. Alloy 601 forged fittings are extensively used for the thermo-well sheathing material and are also used for the oxygen injection tubes into the metal and in the glass metal industry. The best property of Inconel UNS N06601 Threaded Forged Fittings is that it is resistant to the high-temperature oxidation wherein the oxidation resistance is enhanced by the content of aluminum. Inconel 601 Socketweld forged fitting is used often into the electrical resistance heating wires, woven wire conveyors and in burner nozzle.
Alloy 601 threaded forged fittings are used into the tube support grid barriers and in the ash-handling system for the power generation tools. The Inconel 601 Forged Fittings is nickel and chromium stabilized that further provides confrontation to various harsh media as well as the high heat atmosphere. Inconel 601 or UNS N06601 Forged Fittings is having very good resistance ability to the high mechanical strength and aqueous corrosion. These forged fittings are having the ability to be readily formed, welded and machined. This Alloy 2.4851 forged fittings can be easily machined by making use of the traditional machining techniques that are used for the iron-based alloying elements. Both heat and corrosion resistance of the alloy is making it an ideal choice for the furnace parts in operations like nitriding, carburizing, annealing and various other heat treatment functions. Inconel 601 Forged Fittings due to good metallurgical stability and creep & rupture strength has become an ideal option.
To the clients, it is provided in different sizes, specifications, standards, types, classes and also in custom-made standards & specifications for fulfilling all demands. Before these Inconel 601 Forged Fittings are supplied to the clients it is well tested. The tests done are hydrostatic test, flaring test, SSC & HIC test, hardness test, macro & micro test, bend test, impact test, UT test and many more.
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Inconel 601 | 2.4851 | N06601 | NCF 601 | NA 49 | XH60BT | NC23FeA | NiCr23Fe |
| Specifications | ASTM B564 & ASME SB564 |
| Dimensions | ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
| Size | 1/8” NB to 4” NB (Socketweld & Screwed-Threaded) |
| Type | Socketweld Fittings, Screwed-Threaded Fittings |
| Class | 2000 LBS, 3000 LBS, 6010 LBS, 9000 LBS |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 601 | 0.10 max | 1.0 max | 0.5 max | 0.015max | 1.0 max | Balance | 58.0 – 63.0 | 21.0 – 25.0 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 601 | 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80,000 , MPa – 550 | Psi – 30,000 , MPa – 205 | 30 % |
