Gayatri Tubes is offering the wide ranges of SS 316 / 316L fasteners to the global clients. It is made available to them at various standards, dimensions, sizes, lengths, etc. According to the different demands of different clients based upon the requirements, it is offered at customized specifications. These UNS S31600 and UNS S31603 fasteners are designed according to the set manufacturing norms and product quality standards (JIS, EN, and BS, etc). The addition of alloying elements like molybdenum and nickel in little proportion is making UNS S31600 fasteners right for the architectural applications in severe settings, from the polluted marine atmosphere to the zones with sub-zero temperatures. SS 316 fasteners are having very good forming and welding abilities.
Furthermore, the austenitic construction of SS 316L Bolts is providing it very good durability. As compared to the chromium and nickel austenitic steel, these SS 316L fasteners are providing excellent creep and rupture strength and high tensile strength properties even at high temperatures. The types in which these fasteners are made available to the clients are SS 316 nuts, SS 316L Bolts, SS 316L machine screws, SS 316 machine bolts & nuts, SS 316L ASTM A194 fasteners. Also, the other types include SS 316 L high nuts, SS 316 tower bolts, SS UNS S31603 T nuts and so on.
SS 316 hex head bolts rust whereas exposed stainless is unharmed. SS 316L hex head nuts are having low carbon. When it is welded, the chromium carbide that forms don’t depletes chromium and stainless corrosion is impacted deleteriously. SS 316L square nuts are easy to form and shape that in turn might affect the residual stress left the steel once fitting up and forming for the welding. SS 316L eye nuts welding consumable is based upon the low carbon addition for ignoring inter-crystalline corrosion risks. SS UNS S31600 / S31603 Fasteners are sent for the test for checking the product strength and quality so that only the premium quality of the same is delivered. Few tests done are IGC & PMI tests, toughness test, pitting resistant test. More tests like chemical composition checking, mechanical strength checking, flattening-flaring test, and macro- micro test and so on.
| STANDARD | UNS | WNR. | AFNOR | EN | JIS | BS | GOST |
| SS 316 | S31600 | 1.4401 / 1.4436 | Z7CND17‐11‐02 | X5CrNiMo17-12-2 / X3CrNiMo17-13-3 | SUS 316 | 316S31 / 316S33 | - |
| SS 316L | S31603 | 1.4404 / 1.4435 | Z3CND17‐11‐02 / Z3CND18‐14‐03 | X2CrNiMo17-12-2 / X2CrNiMo18-14-3 | SUS 316L | 316S11 / 316S13 | 03Ch17N14M3 / 03Ch17N14M2 |
| Specifications | ASTM F593, F1554 / ASME SF593, F594, F1554 |
| Standard | DIN, ASTM, BS and all International Standards |
| Nuts Size | M3 - M56 | 3/6" to 2" | Custom Sizes |
| Bolt / Screw Size | M3 - M56 | 3/6" to 2" | Custom Sizes |
| Washers Size | M3 - M56 | 3/6" to 2" | Custom Sizes |
| Machine Screws Size | M1.6 - M12 |
| Self Tapping Screw Size | No.2 - No. 14 |
| Length | 3 mm to 200 mm |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
| 316 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 16.00 - 18.00 | 2.00 - 3.00 | 11.00 - 14.00 | 67.845 min |
| 316L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 16.00 - 18.00 | 2.00 - 3.00 | 10.00 - 14.00 | 68.89 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
