Guaranteed on time delivery
Gayatri Tubes exports and manufactures high quality of SS 316TI Sheet Plate / Structurals. We provide plates which are beneficial in the annealing procedure. Moreover, we offer quality stainless steel with better resistance and excellent general corrosion. SS 316TI Sheet Plate is generally used for the fabrication of equipment to prevent corrosive conditions. Moreover, the plates offer stress rupture and higher creep properties. It is known to maintain excellent corrosion resistance, especially when the temperature is between 700 degrees F to 1600 degrees F. Furthermore, its applications include a gas turbine, steel piping, and boilers in power plant industries. It also prevents post-weld from annealing while welding. Besides this, the fusion and resistance method is used to weld SS 316TI Sheet Plate. In sulfuric acid, our SS 316TI Sheet Plate, our SS 316TI Sheet Plate, withstand with it.
Our Austenitic Stainless Steel 316TI Sheet Plate is used in power generation, seawater equipment, specialty chemicals, heat exchangers, gas processing, and photo-chemicals. Furthermore, the pulp and paper industry is also in need of it. Moreover, petroleum and offshore oil drilling companies also make use of SS 316TI Sheet Plate. The sheets are ductile and robust and thus can be used as swaging, roll form, deep drawing, bent, and cold heading. Moreover, it is hot forming and offers the best corrosion resistance. In construction and building, it turns into products siding awnings, gutters, and carports. They are even come in different categories like stainless steel sheet, rolled sheet coil, steel shim sheet, etc. We provide SS 316TI Sheet Plate that can be bent and cut is available into different shapes. It is used to fabricate different objects from metal sheets.
In general, aerospace, transportation military make use of Stainless Steel 316TI Sheet Plate. Many industries use it for storage tanks. It has aluminum alloys and thus it becomes rigid at supercold temperatures. Apart from this, these plates are used in railcars and ship sectors. Furthermore, SS 316TI Sheet Plate is used in producing much military armor. Moreover, we also provide metal testing services, documentation, quality assurance, and package & delivery services. Furthermore, we offer certified and quality SS 316TI Sheet Plate / Structurals to our customers.
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 316Ti | 1.4571 | S31635 | SUS 316Ti | 320S31 | 08Ch17N13M2T | Z6CNDT17‐123 | X6CrNiMoTi17-12-2 |
| Specifications | ASTM A240 / ASME SA240 |
| Dimensions | ASTM, ASME, and API |
| Sheets Plates Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets Plates Thickness | 4mm-100mm |
| Sheets Plates Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Angle Size | 3/4″ THRU 8″ |
| Angle Thickness | 1/8″ thru 5/8″ |
| Beams Weight | 19.6 |
| Beams Length | 20′to 22′Random length |
| Channels Size | 30mm*15mm*15mm*1mm-300mm*150mm*150mm*30mm |
| Channels Diameter | 50x37x5mm |
| Surface Finish | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, chequered, embossed, hairline, sand blast, Brush, etching, Hot rolled plate (HR), Cold rolled sheet (CR), SATIN (Met with Plastic Coated) etc |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Form | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
| SS 316Ti | 0.08 max | 2.0 max | 0.75 max | 0.045 max | 0.030 max | 16.00 - 18.00 | 2.00 - 3.00 | 10.00 - 14.00 | 68.395 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1399 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
