Gayatri Tubes is the biggest exporter, manufacturer, supplier, and wholesaler of Inconel 625 Flanges in all shapes and sizes. We provide a high quality of flanges which is used in many industries and offer the best corrosion resistance property. We manufacture the flanges available in different specifications, different in sizes and shapes, different thicknesses, lengths, radius, classes, dimensions, and diameters. There are different types of flanges available such as- lap joint flanges, threaded flanges, weld neck flanges, socket weld flanges, slip-on flanges, weld long neck flanges, forged flanges, reducer flanges, and blind flanges. Inconel 625 is a chromium nickel molybdenum alloy which has high corrosion resistance and good strength. Because of its high resistance property, this grade is used in the nuclear industry, automotive, oil, and gas, chemical industry.
Inconel 625 flanges are a nonmagnetic alloy and resistance to corrosion and oxidation. This flange provides high toughness and strength at the high temperature like cryogenic to 1093 degree c. The small amount of molybdenum and columbium mix with nickel and chromium alloy which increases fatigue and resistance to stress chloride corrosion cracking. Flanges are used to join two or more pipes equipment together like a valve, pipes, pump, etc. We manufacture Inconel 625 flanges according to our customer’s requirement. Inconel 625 threaded flanges resistance to corrosion in acidic environment and used in high-temperature range application. Ring joint type Inconel 625 flanges are used in chemical and seawater applications because it resists to acid and many corrosion and also rust-free. The weld neck Inconel 625 flanges are easily resistance to pitting corrosion and crevice corrosion, oxidation, etc.
Inconel 625 flanges are used in many industries like chemical industry, petrochemical industry, oil and gas industry, marine and seawater application, pulp, and paper industry, etc. These flanges are also used in boiler equipment, chemical equipment, surgery equipment, power generation plant, gas process, food process, and many more. We conduct different types of tests, before delivery our product like macro test, micro test, chemical test, mechanical test, hardness test, toughness test, impact test, eddy current test, destructive test, intergranular test, and other tests. We offer the best packaging facility in different forms like plastic wrap, wooden box, carton box, etc.
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Inconel 625 | 2.4856 | N06625 | NCF 625 | NA 21 | ХН75МБТЮ | NC22DNB4M | NiCr22Mo9Nb |
| Specifications | ASTM B564 / ASME SB564 |
| Dimensions | ANSI/ASME B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, etc. |
| Size | 1/2″NB TO 60″NB |
| Flange Face Type | Flate Face (FF), Raised Face (RF), Ring Type Joint (RTJ) |
| Class / Pressure | 150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 etc. |
| DIN Flanges | DIN 2527, 2566, 2573, 2576, 2641,2642, 2655, 2656, 2627, 2628, 2629, 2631, 2632, 2633, 2634, 2635, 2636, 2637,2638, 2673 |
| JIS Flanges | JIS B2220 5K, JIS B2220 10K, JIS B2220 16K, JIS B2220 20K |
| BS Flanges | BS4504 PN 6, BS 4504 PN 10, BS4504 PN 16, BS4504 PN 25, BS4504 PN 40, BS 4504 PN 64, BS 4504 PN 100, BS 4504 PN 160, BS 4504 PN 250, BS 10, BS Table D, BS Table E, BS Table F, BS Table H. |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 625 | 0.10 max | 0.50 max | 0.50 max | 0.015 max | - | 5.0 max | 58.0 min | 20.0 - 23.0 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 625 | 8.4 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 517 | 42.5 % |
