Gayatri Tubes is the prominent manufacturer, supplier and exporter of the Titanium Gr 5 Forged Fittings. We are supplying forged fittings all over the globe. However, we are providing forged fittings in various specifications. Some of the specifications in which the fittings are available are dimensions, shape, size, surface finish, end finish, and many other specifications. All the national and international quality standards are followed while manufacturing the types of forged fittings for the clients. We are providing them with all the forged fittings according to their needs and expectations for using in industries. However, one such type of pipe fittings that are manufactured by following the forging process is the forged fittings. They are available for various applications. This provides support to industrial applications. In this way, all the applications are joining together to perform a certain task. There are many types of forged fittings. Tees, elbows, couplings, unions, bushings are some of the types of forged pipe fittings that are available. They are used in industrial applications to change the direction of the pipes. With the help of reduced tees and reducing elbow, you can even reduce the size of the workflow of the pipe.
Titanium Gr 5 is having good tensile strength properties that are useful in the creep resistance in the elevated temperatures. However, this is also having some elements of carbon that gives the Titanium 3.7165 Socket weld Forged Fittings toughness and high tensile strength. Titanium alloys are good at working in the natural industrial processing environments. Because of these characteristics, all the clients prefer the products manufactured by Gayatri Tubes. The forged fittings are used in the industrial applications and the working pipes. Petrochemicals, pharmaceuticals, oil and gas and various other industries are using the forged fittings.
Titanium UNS N56400 Threaded Forged Fittings are well tested before delivery to the clients. This is done to ensure the clients that all the products are quality tested and firmly manufactured. Some of the tests which are performed are hardness test, hydrostatic, ultrasonic, micro, macro, positive material identification and intergranular corrosion tests. The forged fittings are also packed as per the expectations of the clients.
| STANDARD | WERKSTOFF NR. | UNS |
|---|---|---|
| Titanium Gr. 5 | 3.7165 | N56400 |
| Specifications | ASTM B381 & ASME SB381 |
| Dimensions | ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
| Size | 1/8” NB to 4” NB (Socketweld & Screwed-Threaded) |
| Type | Socketweld Fittings, Screwed-Threaded Fittings |
| Class | 2000 LBS, 3000 LBS, 6010 LBS, 9000 LBS |
| Grade | Ti | C | Fe | H | N | O | Al | V |
|---|---|---|---|---|---|---|---|---|
| Ti Grade5 | 90 min | - | 0.25 max | - | - | 0.2 max | 6 min | 4 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|---|
| Titanium Gr. 5 | 4.43 g/cm3 | 1632 °C (2970 °F) | Psi – 138000 , MPa – 950 | Psi – 128000 , MPa – 880 | 14 % |
