Gayatri tubes are one of the leaders in the manufacturing and supplying of good quality of SMO 254 Rod, Bars, Wire, Wire Mesh. We manufacture our products following the international standards and so our products are certified. We also export our products to several different countries. Our products are famous for their reliability. We have a product of different sizes and designs and also offers to manufacture custom based designs for our customers.
SMO 254 is a high quality of alloy of stainless steel. They are developed with prime use in the areas of seawater as they can protect themselves from the aggression of chloride salts. It contains carbon, silicon, manganese, phosphorous, silicon, chromium, nickel, molybdenum, and many more elements.
They offer excellent resistance to pitting and crevice corrosion and also from general corrosion. They are of higher strength than normal stainless steel. They also offer good weldability. Fabrication of the alloy is also easy and can easily be bending and easy machining is possible. Care should be taken in the case of abrasion with copper because it can crack. The rods, bars, and wire, wire mesh are used in areas of manufacturing of equipment for handling seawater. This device includes seawater cooling, cooling water pipes, ballast water systems, firefighting equipment and many more. They are also used in hydraulic and instrumentation tubing purposes. They are also used in areas in gas production, pulp bleaching equipment, tanks, and pipelines parts.
Some of the important certificates include raw material certificate, radiography test report and third party inspection report. Testing consists of mechanical testing, hardness testing, chemical analysis, PMI testing, flattening test, micro, and major test, pitting resistance test, flaring test. Important documentation includes an invoice, packaging details with weight and number of units with the size. Fumigation certificates, material traceability records, quality Assurance plan, heat treatment chart, and material guarantee are also included.
We manufacture good quality SMO 254 Rod, Bars, Wire, Wire Mesh. Our products have also passed various lab tests. We also have adequate stock of our products. We ensure safe packaging and transportation of our products to save them from any damage caused by transportation.
| STANDARD | WERKSTOFF NR. | UNS | JIS | SIS | GOST | AFNOR | EN |
| SMO 254 | 1.4547 | S31254 | - | 2378 | - | Z1 CNDU 20.18.06Az | X1CrNiMoCuN20-18-7 |
| Specifications | ASTM A276 / ASME SA276 |
| Standards | DIN, ASTM, ASME, BS and all International Standards |
| Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Diameter | Outside Diameter in the range of 4mm to 500mm |
| Width | 1m to 48″ |
| Hex Bars | 18mm – 57mm (11/16″ to 2-3/4″) |
| Square Bars | 18mm – 47mm (11/16″ to 1-3/4″) |
| Flat Bars | 1/2” to 10” in the thickness range of 2mm to 150mm, |
| Wire Length | Max 12000 mm |
| Wire Mesh Length | 30m to 100″ |
| Wire Diameter | 5.5 – 400 mm |
| Finish | Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish |
| Length | 1 to 6 Meters, Custom Cut Lengths |
| Form | Round, Square, Hex (A/F), Rectangle, Billet, Ingot, Forging, Wire Mesh, Hexagonal Wiremesh, Welding Wiremesh, Netting Wiremesh, Woven Wiremesh, Spring Steel wire mesh, Fencing Wiremesh Etc |
| Grade | % | Ni | Cr | Mo | Cu | N | C | Mn | Si | P | S |
| SMO 254 | Min. | 17.5 | 19.5 | 6 | 0.5 | 0.18 | |||||
| Max. | 18.5 | 20.5 | 6.5 | 1 | 0.22 | 0.02 | 1 | 0.8 | 0.03 | 0.01 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| SMO 254 | 8.0 g/cm3 | 1320-1390 ℃ | 650 | 300 | 35 % |
